ISO 4406, Hydraulic fluid power — Fluids — Method for coding the level of contamination by solid particles ISO 5598, Fluid power systems and components — Vocabulary ISO, Hydraulic fluid power — Calibration of automatic particle counters for liquids. ISO 4406 12/9/6 cleanliness level before it reaches the pressurized fuel system. ISO 4406 12/9/6 Cleanliness Code. Required by diesel fuel injector manufacturers. 64 times cleaner than fuel entering equipment at manufacturer recommended ISO 4406 18/16/13 cleanliness level. Noncompliance may void engine warranties. ISO 4406 is widely used in hydraulic and diesel fuel applications. It is used to report cleanliness levels and verify pass/fail criteria for new hydraulic oil and diesel fuel shipments. ISO code data from equipment rolling off assembly lines can be used as a quality tool to ensure system cleanliness and reduce warranty costs.

The most critical quality of hydraulic fluid you should consider is that of cleanliness. We refer to the size and quantity of particle contamination when discussing cleanliness, and so that we are all on the same page, standards were created for measuring and expressing this quality. Although the standard for oil cleanliness has changed over the years, we’re at a point in history when we all seem to agree on the method to test and express fluid contamination. This standard is world-wide, which for the fluid power industry and its plethora of global organizations, is quite astonishing in and of itself.

ISO 4406:1999 is the current method for coding the level of contamination by solid particles, as spelled out by the International Organization for Standardization, which is more affectionately known by its acronym, ISO. Its method has been developed to test and measure the average size and quantity of particles within a given volume of fluid, which in this case is one milliliter.

Civilization 5 iso full download. The particles are measured by specialized machines using a laser to count the size and number of particles breaking the beam as they flow past. Based on the data collected from the machine, three sizes of particles considered most damaging in a hydraulic system are averaged out and expressed as per milliliter. The particle sizes are 4, 6 and 14 μm, chosen because of their potential to cause damage between moving surfaces separated by full film lubrication, such as the spool and body in a directional control valve. To give you an idea of how fine even the largest 14-μm particle is, note that it is only just over ½ a thousandth of an inch.

Each of the defined particle sizes are expressed in a given range, rather than the actual particles measured in the test. This allows for both easy expression and forgiving test results, as no particle counter can accurately measure every single 4-μm particle in a milliliter of fluid. The number of particles of each size is expressed as a single number between 0 and 28, where 0 is exactly zero particles, and 28 represents up to 2.5 million particles per ml. Both numbers are rare extremes, as even new oil has infinitely more particles than 0, and if you have 2.5 million of any given particle size, you’re in a whole heap of trouble.

If you refer to the attached diagram, you can see the numbers are first expressed in 4 μm, with 6 and 14 μm following, respectively. Each number represents a range, and in the example, 22 represents between 20,000 and 40,000 of the 4- μm particles in just one milliliter of fluid, even though the machine measured 22,340 particles. It goes on to show between 1300 and 2500 6- μm particles, and between 40 and 80 14- μm particles.

Every number represents double the range of particles, and this is an important consideration. This means that an ISO Code of 22/18/13 has quadruple the particles as an ISO Code 20/16/11, so don’t be misled by small increases in the ISO Code. Because this system is now a worldwide standard, hydraulic manufacturers publish minimum requirements of ISO 4406 cleanliness. A piston pump manufacturer would specify at least 19/17/14, for example.

So now that you’re familiar with the ISO cleanliness code, you can monitor and decipher your quarterly oil sample reports (you are sampling your oil quarterly, right?).

Abstract Preview

ISO 4406:2017 specifies the code to be used in defining the quantity of solid particles in the fluid used in a given hydraulic fluid power system.

General information

• Publication date : 2017-08
  Corrected version (en) : 2018-03
• Number of pages : 6
• :

• ICS :

Iso 4406 Pdf Parker

• CHF38

Life cycle

A standard is reviewed every 5 years

Iso 4406 Pdf

• 40
• 50
• 60
  Publication
• 90.92
• 95

Revisions / Corrigenda

• Previously
  ISO 4406:1999

• Now under review
  ISO 4406:2017
• Revised by
  ISO 4406
